Sta-Rite 72 Sq/Ft Modular D.E. Filter

The Sta-Rite S7MD72 System:3 Modular D.E. Filter delivers exceptional water clarity for in-ground pools, spas, and water features. Combining the superior filtration of diatomaceous earth (D.E.) with a user-friendly modular design, this filter ensures efficient operation and easy maintenance.​

Key Features:

• 72 Sq. Ft. Filtration Area: Provides high-capacity filtration, capturing particles as small as 5 microns for crystal-clear water.​

• Balanced Flow Design: Ensures even distribution of water over the filter media, optimizing performance and extending time between cleanings.​

• Durable Dura-Glas™ Construction: The two-piece tank housing is made from Sta-Rite’s glass-reinforced composite resin, offering strength and corrosion resistance.​

• Posi-Lok™ Clamps: Allow for safe and easy access to the filter module, simplifying maintenance tasks.​

• Dual Drain Plugs: Facilitate quick draining and winterization, enhancing convenience.​

• Contemporary Design: Sleek matte black finish complements any pool setting.​

Specifications:

• Model: S7MD72​

• Filtration Area: 72 sq. ft.​

• Flow Rate: 72–144 GPM​

• Turnover Capacity: Up to 64,800 gallons in 10 hours​

• D.E. Required: 11 lbs.​

• Port Size: 2″ NPT​

• Maximum Operating Pressure: 50 PSI​

• Maximum Water Temperature: 104°F (40°C)​

• Dimensions: Approximately 26.75″ L x 26.75″ W x 41.5″ H​

This filter is compatible with Sta-Rite’s 18201-0300 multiport valve and 263053 slide valve, offering versatile installation options. Its efficient design and robust construction make it an excellent choice for maintaining a healthy swimming environment.​
